3304B NA-2
3304B NA-1-1

Horsepower:
          95HP
Dimensions:
          20’L x 9’ W x 11' H
Control system:
          Murphy eics

KEY HIGHLIGHTS:

  • Optimized cylinder selection maximizes operational flexibility and utilization of engine power
  • Pre-engineered design for expedited delivery and accelerated time-to-market
  • Factory load tested equipment and minimal assembly to bring your operation online quickly

PACKAGE FEATURES:

  • Scrubbers ASME coded with 1/16" corrosion allowance
  • Piping adheres to ASME B31.3
  • API 5th Edition DA2 pulsation and vibration analysis performed for smooth operation
  • Murphy Centurion Panel
  • Rugged four-runner I-beam skid with environmental containment designed to be set on a prepared earth pad
  • Coalescing type fuel gas filter installed for maximum engine protection
  • Hot gas bypass on aftercooler section
  • Inlet spool piece with basket strainer
  • Suction-based speed control
  • Automatic cooler louvers
  • Heat tracing
  • Insulated scrubbers
  • Automatic makeup/recycle valve

PACKAGE OPTIONS:

  • 0.5G NOx emissions setting
  • Mounted oil day-tank
cta_image

THE WOLF - PERMIAN BASIN CASE STUDY

High-Pressure Gas Lift (HPGL) delivers strong artificial lift performance without the need for well intervention. But is it really as effective as ESP gas lift configurations? We partnered with 111-year-old operating company SM Energy to find out.

Email the Case Study

Engine: Caterpillar 3304B

  • Dependable industry standard G3300 platform backed by Caterpillar's global dealer network
  • Engine Integrated Control System (EICS®)
  • 95 BHP @ 1800 RPM
  • 1.0g NOx, 2.0g CO standard emissions setting
  • Onboard alternator for reliable 24V power
  • Electric starter (24V) for reliable starting independent of gas supply
  • Operator interface included for setup and service without a laptop
  • Pressure-based automatic speed control

Compressor: ariel jgp/2

  • World Standard Compressor backed by Ariel service and support network
  • Available 72-month warranty
  • VVCPs included on 1st and 2nd stages for maximum operational flexibility
Cylinder Size Pressure
1st Stage Cylinder 6.125” JG 635 psig
2nd Stage Cylinder 4.125" P-HE 1270 psig
3rd Stage Cylinder 2.5" P-CE 1500 psig

COOLER: INDUCED DRAFT, VERTICAL DISCHARGE

  • Combined engine, compressor and gas cooling improves service access and eases package maintenance

  • 15°F approach to ambient on aftercooler

  • Vertical section design simplifies cooler maintenance

  • Vertical air discharge minimizes noise and hot air recirculation

  • Performance 3304B NA-JGP/2 |

  • Engine: Caterpillar 3304B |

  • Compressor: Ariel JGP/2
